Plastic Spool Reel Wheel Winding Thread Bobbin Cone Making Small Injection Molding Machine
machine type Hybrid, Hydraulic distance between tie bars 470X470mm plastic processed PP, PC, ABS, PET, PVC, FRPP/PVC, PPR, HDPE, PA, Polystyrene, PE, LDPE, HDPE/PP, ABS/PP, PE/PP style Horizontal key selling points High-Accuracy ejector number 9 core components Bearing, Motor, Pump, Gear, PLC, Pressure Vessel, Engine, Gearbox, Screw machinery test report Provided video outgoing-inspection Provided plasticizing […]
Professional Solutions: Offering high-quality thread solutions and OEM services.
Advanced Technology: Ensuring durability, colorfastness, and consistency.
Sustainability: Using eco-friendly materials and processes.
Global Network: Reliable, timely delivery worldwide.
Exceptional Service: Helping customers achieve their vision with top-quality products.
Introduction
Chinee Threads Co., Ltd. specializes in professional thread solutions and offers comprehensive OEM services. Whether you need customized designs, high-quality production, or specially tailored thread products, we provide flexible and reliable supply solutions to meet your unique business needs. Partner with us to bring your vision to life and deliver exceptional products and services.
| machine type | Hybrid, Hydraulic | distance between tie bars | 470X470mm |
| plastic processed | PP, PC, ABS, PET, PVC, FRPP/PVC, PPR, HDPE, PA, Polystyrene, PE, LDPE, HDPE/PP, ABS/PP, PE/PP | style | Horizontal |
| key selling points | High-Accuracy | ejector number | 9 |
| core components | Bearing, Motor, Pump, Gear, PLC, Pressure Vessel, Engine, Gearbox, Screw | machinery test report | Provided |
| video outgoing-inspection | Provided | plasticizing capacity(g/s) | 35 |
| injection weight (g) | 347 | injection rate (g/s) | 347 |
| weight (kg) | 4500 | power (kw) | 28.5 |
| mold height(mm) | 150 - 500 mm(5.91-19.69in) | ejector stroke(mm) | 130 |
| ejector force(kn) | 46 | theoretical shot volume(cm³) | 381 |
| screw speed (rpm) | 0 - 160 rpm | screw diameter (mm) | 45 |
| Screw L/D Ratio | 22 | open stroke(mm) | 430 |
| Product name | Plastic Injection Moulding Machine | After-sales Service Provided | 1 Year |
| Applicable materials | PS PE PP PVC ABS etc. | Function | Making Plastics Parts |
| Application | Inserting Plastic Products | Keyword | Plastic Machinery Equipment |
| Model | BJ-170T |
