KC522A Automatic Bobbin Winder Machine Electric Yarn Winder Thread Cone Winding Machine
voltage 380 V automatic grade Automatic power(w) 400 W(0.54hp) core components Motor machinery test report Provided video outgoing-inspection Provided Weight (KG) 500 production capacity 300 memory capacity 200 dimension(l*w*h) 1600 Machine structure Single side , single layer Spindle gauge 460mm Min./Max. No. of spindles 4/20 (Max. number of spindles per oil feeding system: 20) Take-up […]
Professional Solutions: Offering high-quality thread solutions and OEM services.
Advanced Technology: Ensuring durability, colorfastness, and consistency.
Sustainability: Using eco-friendly materials and processes.
Global Network: Reliable, timely delivery worldwide.
Exceptional Service: Helping customers achieve their vision with top-quality products.
Introduction
Chinee Threads Co., Ltd. specializes in professional thread solutions and offers comprehensive OEM services. Whether you need customized designs, high-quality production, or specially tailored thread products, we provide flexible and reliable supply solutions to meet your unique business needs. Partner with us to bring your vision to life and deliver exceptional products and services.
| voltage | 380 V | automatic grade | Automatic |
| power(w) | 400 W(0.54hp) | core components | Motor |
| machinery test report | Provided | video outgoing-inspection | Provided |
| Weight (KG) | 500 | production capacity | 300 |
| memory capacity | 200 | dimension(l*w*h) | 1600 |
| Machine structure | Single side , single layer | Spindle gauge | 460mm |
| Min./Max. No. of spindles | 4/20 (Max. number of spindles per oil feeding system: 20) | Take-up tubes | A tube: cone; Y tube: King spool |
| Linear speed | Up to 1100m/min (depend on the process parameters) | Traverse | 76mm~152mm(±3.5mm,depend on the tank size) |
| Yarn count | Up to 3300D | Take-up package diameter | Up to 105mm (85-105mm) |
| Supply package diameter | Up to 320mm | Rated power | 300W/spindle |
